Architectural cladding system using a laminated piece of thin aluminum (.020 or .030) to a core of poly or fire rated material the backed with another thin piece of aluminum created an overall thickness of 4mm (most typical) or 6mm. Once color choices have been made and approved from customer, we can order the flat sheet. When the material is received at our shop, we inspect for manufacturing defects or damage from shipping. Using field verified dimensions we write programs for our CNC mill and then cut and V-Groove the back side of the panels to make fine crisp corners. There are many different types of attachment the main two that we use at Progressive Building Systems are Wet-joint & Rainscreen (dry-joint).
- A wet joint system is sealed system with .5” caulked joint.
- The Dry-Joint (rainscreen) system is and open (not sealed) system with .5” joints backed with 1.5” piece of spline to cover the extruded alum. Clips. used for attachment.
PBS Composite panels (in 4mm or 6mm) combine unique design with ease of installation. They are durable while maintaining light weight. The aluminum composite panels will give your building a clean, modern look.
